Peerless Pumps Equipment

TU/TUT Horizontal Split Case Multi-Stage Pumps

OIP (1)
Peerless Pumps
Pump Equipment

TU/TUT Horizontal Split Case Multi-Stage Pumps

Overview

The multi-stage pump casing material is a minimum of class 40 cast iron. Alternate volutes are reversed, balancing transverse pressures on running members. The bearing bracket supports are cast integral with the lower casing half for permanent alignment of bearings and all rotating parts. Bronze, renewable casing rings are doweled and shouldered in the casing. Cast bronze, enclosed type, single suction impellers are carefully machined and are dynamically balanced for vibration-free performance and longer bearing life. Impellers are keyed to the shaft for positive driving. Bronze impeller wear rings are available on the TU and TUT type pumps.



Specifications

Capacities: Up to 6,000 gpm (1,636 m3/hr)

Head: Up to 1,600 feet (488m )

Pressure: Up to 700 psi (48.26 bar)

Horsepower: Up to 1,300 hp (969 kW)

Temperature: Up to 300°F (149°C)

Drives: Motors, engines, steam turbines, combinations

Liquids: Water and clear liquids

Materials: Cast iron, bronze fitted as standard. Other materials are available.
